High-speed wireless transmission
High reliability: uses software watchdog and hardware watchdog for dual-protection
High security：supports VPN functions
Versatility: provides various basic functions
Efficient use: provides traffic management technology and intelligent bandwidth distribution technology
Ease of maintenance: supports automatic remote software upgrade
High adaptability, IP66 protection
| Hardware | |
| Protocol | LTE: 3GPP WiFi: IEEE 802.11b/g/n, 300Mbps |
| Frequency | GD500/GD600: TDD 1.4G/1.8G GD504/GD604: TDD 400M GD506/GD606: TDD 600M Wi-Fi: 2.4G: 2401 - 2483MHz |
| LTE Bandwidth | 1.4MHz/3MHz/5MHz/10MHz/15MHz/20MHz |
| Tx Power | LTE: 23±2dBm Wi-Fi: 17±2dBm |
| Antenna | External antenna, standard configuration, 3dBi isotropic |
| Ethernet Interface | 10/100M auto-sensing Quantity: 5 (GD50X)/1 (GD60X) |
| Port | 1×RS232, 1× RS485 (GD50X) |
| Storage interface | 1× External Mini SD card (GD50X) |
| Dimensions (W×H×D) | 233mm×26mm×113mm (GD50X) 270mm×270mm×67mm (GD60X) |
| Weight | 760g (GH50X) 3.2Kg (GD60X) |
| Power supply | Φ2.1power plug, DC9 - 24V (GD50X) Ethernet power supply, DC9 - 24 V (GD60X) |
| Installation mode | Rail mounted/rack-mounted/wall-mounted (GD50X) Pole-mounted (GD60X) |
| Power consumption | ≤6W |
| Operating temperature | Operating temperature: -25℃ to 60℃ (GD50X)/-40℃ to 60℃ (GD60X) Storage temperature: -40℃ to 85℃ (GD50X/GD60X) |
| Operating humidity | 5% - 95% No condensation |
| Dust and Water Resistance | IP31 (GD50X)/IP66 (GD60X) |
| VPN Functions | |
| PPTP/L2TP/GRE | |
| IPsec | Supports the certificate and pre-shared key Supports the NAT function Supports the DPD function Supports the AES, DES, 3DES Supports MD5-HMAC and SHA1-HMAC Interconnects to the devices of the mainstream VPN manufactures |
| Network Functions | |
| Supports DDNS | |
| Supports the NAT, Multiple Host & Multiple APN functions | |
| Supports the DHCP server | |
| Supports the MAC address binding function | |
| Supports the DMZ | |
| Supports the interface mapping function | |
| Support VLAN (GD50X) | |
| Basic Functions | |
| Configures the remote EMS software and browser | |
| Supports the log record function of the local machine and log server | |
| Supports Web upgrade, unified network management upgrade, SD card upgrade (GD50X), remote upgrade (GD60X) | |
| Supports CLI debugging | |
| Supports SIM and USIM card | |
| Supports the real-time status display/rrate chart (GD50X) | |
| Supports the network clock synchronization function | |
| Restores to the factory settings through the external reset button or software | |
| Supports PLMN selection and cell selection. Scan mode is used for the cell selection. CPE can only connect to dedicated cell when cell lock | |
| Supports the configuration import and exp | |
| Supports for QoS of GBR and Non-GBR Services | |
| LTE link keep-alive function | Provides the ICMP heartbeat detection function Provides automatic repair technology after disconnection |
| Supports EMS software | Supports the SNMP protocol and the TR069 protocol or customizes EMS software |
| Network status monitoring | Monitors the network status, VPN status, and network service signal quality through the Web |
| Firewall | Configures multiple firewall filtering rules to filter the designated IP addresses or interfaces |
| Route management | Configures dynamic routes and adds multiple route entries |
| General Disclaimer: the specifications in this document are in accordance with the applicable standard test. Due to the continuous technology development, Caltta may change the specifications without timely notice. | |
